The Titan N-180 electric water heater is the third most powerful Titan water heater. Like every Titan electric water heater, the Titan N-180 will provide instant hot water while the hot water faucet is kept open. This model is commonly used for large houses and colder states.

The TITAN N-180 is rated at 18 KW, 240V, 75 Amps; which is ideal for a wide range of applications including residential and some commercial applications. One TITAN N-180 electric water heater will keep your water hot and ready to use whether you live in a colder state or you have a big house where more than one bathroom is going to be used simultaneously.

The TITAN N-180 electric water heater is build with high quality components to assure high level of reliability even under continuous use and hard water.

Every Titan N-180 tankless water heater comes with a 10 year warranty on the heat exchange and all other parts are guaranteed for one year. Installation is fast and simple requiring no venting, and its compact size allows installation basically everyplace.

Technical Specifications/ Temperature Rise Chart

MAX FLOW	KW/HR	VOLTS	AMPS	1.0gpm	1.5gpm	2.0gpm	2.5gpm	3.0gpm	3.5gpm	4.0gpm	4.5gpm	5.0gpm
5.0 GPM	18	220	75	122 deg	81 deg	61 deg	49 deg	41 deg	35 deg	31 deg	27 deg	25 deg

NOTE: THE N-180 NEEDS A 200AMP SERVICE
Double installation, two wires coming out of unit and it takes 2x40 amp double pole breakers and 2x8awg wires

Product Measurements

MODEL	CURRENT	POWER	VOLTAGE	Weight	DIMENSIONS
N-180	75Amps	18.0KW	240V	12 Pounds	10-½” W x 11-½” H x 4" D
N-210	88Amps	21.0KW	240V	12 Pounds
N-270	112Amps	27KW	240V	12 Pounds

Compliance................................... UL#499
Standards................................... E212386
Tested ...................................... MET Laboratories
NSF/ANSI-372 Compliant................. ETL Laboratories
Dimensions................................... 10-1/2" W x 11-1/2" H x 4" D
Weight...................................... 12 Pounds
Materials..................................... Brass and Copper interior / Steel Casing. No plastics Used
Pipe Fitting.................................. 3/4" Standard Pipe
Pressure Requirements.................... 5 PSI-Min./ 150 PSI-Max
Voltage...................................... 220 VAC Std.
Elements...................................... Dual Incoloy Nichrome
Energy Efficiency............................ Up to 99.5%
Activation................................... 0.4 GPM-on / 0.3 GPM-off
Indicators.................................... LCD Display
Warranty................................... 10 years on casing, 1 year on components
Protection.................................... Digital Temperature Control - Manual Resetable Thermostat
